High Quality 21g Metal Gear 6kg Iron Core Motor 180 Degree Digital Servo DS-S011M Manufacturer and Supplier

21g Metal Gear 6kg Iron Core Motor 180 Degree Digital Servo DS-S011M

DS-S011M servo eliminates mechanical failure and overheating issues with its all-metal gears and efficient heat dissipation system, meeting a wide range of demands from demanding remote control car racing to automation applications requiring micron-level repeatability.

·Iron Core Motor+Metal Gear+Heat dissipation housing

·Equipped with imported high-precision potentiometer, effective life exceeds 500,000 times, can be upgraded to magnetic encoder

·6 kgf·cm Stall Torque +≤0.16 sec/60° Speed +Operating angle 180°

Send email to us

Product Detail

Product Tags

DS-S011M digital servo, featuring a rugged all-metal gear train and iron-core motor, delivers the raw power and exceptional precision required for high-stakes projects. From navigating the rough terrain of a remote-controlled race car to the critical control surfaces of an aerial drone, the DS-S011M is a model of durability and reliability.

Key Features and Functions:

Excellent balance between high torque and light weight:

The powerful 6.5kgf·cm torque, usually found on heavier standard servos, allows designers to reduce the overall load without sacrificing performance, thereby increasing endurance or speed.

High-precision metal gears and durability:

Cheap plastic gear servos can easily "scrape" and fail when subjected to shock or high loads. This can not only cause the model to lose control but also frustrate the hobbyist. The copper gears used in the DS-S011M are able to effectively resist such wear and shock, significantly extending the product life.

Digital Servo：
When the servo is overloaded or stuck, it will be damaged due to overheating or even smoke. Digital servos can provide faster response speed, more precise positioning and stronger holding force due to their higher control frequency.

Application Scenarios

Robotics: Ideal for high-torque applications in robotics, the servo can be employed in various robotic components, including arms, grippers, and other mechanisms requiring powerful and precise control.

RC Vehicles: Well-suited for remote-controlled vehicles, such as cars, trucks, boats, and airplanes, where the combination of high torque, durable all-metal gears, and a low-profile design is crucial for optimum performance.

Aerospace Models: In model aircraft and aerospace projects, the servo's high torque output and durable all-metal construction contribute to precise control of control surfaces and other critical components.

Industrial Automation: The servo can be integrated into various industrial automation systems, including conveyor controls, robotic assembly lines, and other applications requiring robust and precise movement.

Research and Development: In research and development settings, the servo is valuable for prototyping and testing, particularly in projects that demand high torque and precision.

Automation in Compact Spaces: Suitable for applications where maintaining a low profile is crucial, such as compact robotics, small-scale automation, and experimental setups.

FAQ

Q. Do: you test all the goods before delivery?

A: Yes, we have 100% test before delivery. If you need any assistance, please feel free to contact us.

Q: What certifications do your servo has?

A: Our servo have FCC, CE, ROHS certification.

Q. How do l know if your servo are good quality?

A: Sample order is acceptable for testing your market and checking our quality And we have strict quality control systems from raw material incoming until finished product delivery out.

Q: For a customized servo, how long is the R&D time (Research& Development time)?

A: Normally, 10~50 business days, it depends on requirements, just some modification on standard servo or a totally new design item.
